Length(mm) | 13700 |
Width(mm) | 2550 |
Height(mm) | 3940 |
G.V.W.(kg) | 22100 |
Wheelbase(mm) | 6500+1500 |
Seats | 57 |
Fuel Tank (l) | 360 |
Engine Model | YC6M390-30/WP12.375N/ ISME38030 |
Engine Output (kw/rpm) | 288/2100, 276/1900, 284/1900 |
Chassis Model | XMQ6130R1/ XMQ6130R1/ XMQ6130R1 |
Chassis Clutch | SACHES clutch;Single,dry plate,hydraulic distance control,air assistance; |
Chassis Suspension System | Multiple leaf spring, dual-acting hydraulic drum-type vibration damper, front stabilizer bar (Chinese and ZF 6-bag air suspension are optional) |
Chassis Braking System | ABS, double-pneumatic-loop driving braking, with spring energy-stored parking braking. |
Model | Intercity |
Energy | Diesel |
