Length(mm) |
12000 |
Width(mm) |
2550 |
Height(mm) |
3780 |
G.V.W.(kg) |
18,000 |
Max.Speed(km/h) |
120 |
Approach Angle/Departure Angle(°) |
9°/ 9° |
Wheelbase(mm) |
6,000 |
Max.Grade Ability(%) |
30% |
Seats |
44+1+1 |
Fuel Consumption(l/100km) |
29.5/100 |
Fuel Tank (l) |
360 |
Engine Model |
YC6L330-30 |
Engine Output (kw/rpm) |
243/2200 |
Engine Max. Torque (N.m/rpm) |
1280/1200-1400 |
Chassis Model |
XMQ6120R |
Chassis Clutch |
Sachs |
Chassis Suspension System |
Air bag suspension |
Chassis Gearbox |
ZF Auto Transmission |
Chassis Braking System |
Front /Rear drum brake, double circuit air brake system, Chinese Automatic adjustable slack, Chinese ABS |
Front Axle |
Dongfeng Dana |
Rear Axle |
Dongfeng Dana |
Drive Motor |
Prestolite |
Tyre |
Michelin Tubeless tyre |
