Length(mm) |
12000 |
Width(mm) |
2550 |
Height(mm) |
3150/3250 |
G.V.W.(kg) |
17500 |
Max.Speed(km/h) |
69 |
Approach Angle/Departure Angle(°) |
7°/7° |
Wheelbase(mm) |
6100 |
Seats |
32+1 |
Fuel Tank (l) |
220 |
Engine Model |
YC6G270-30/YC6G270-20/C260 20 |
Engine Output (kw/rpm) |
199/2000;199/2200;191/2200 |
Engine Max. Torque (N.m/rpm) |
1080/1400-1600; 1025/1300 |
Chassis Clutch |
φ430 |
Chassis Suspension System |
Leaf Spring Front 4/Rear 5 |
Chassis Gearbox |
QJ1205 |
Chassis Braking System |
Dual-circuit Air Brake |
Chassis Steering System |
Domestic |
Front Axle |
AK153 Front Axle |
Rear Axle |
AK437 Rear Axle |
Tyre |
11R22.5-GITI |
Model |
City Bus |
