KLQ6856/Q |
KLQ6896/Q |
| Engine: | Dongfeng
Cummins EQB180-20 (180Ps)Brazil Cummins B5.9 engine(215Ps)
Chinese Yuchai YC4G
180-20(180)Cummins ISBe220 30(220Ps) EuroIII
ISUZU 6HE1 engine (230Ps)Dongfeng
Cummins EQB210-20 (210Ps )
Brazil Cummins B5.9 engine (215Ps) |
| Clutch: | Diaphragm
spring clutch (395) |
| Gearbox: | Chinese
6 speeds gearbox |
| Propeller
shaft: | Strengthened
propeller shaft |
| Suspension: | Parabolic
leaf spring; Front / rear stabilizer anti-roll bar |
| Axle: | Chinese
front / rear axle |
| Braking: | Front
disc / rear drum brake |
| Dual-circuit
service brake system; Energy storage spring parking brake |
| Steering: | Chinese
power steering gear |
| Tyre: | 8.25R20
radial tyre |
| Others: | Stainless
wheel cover |
| | |
| BODY |
| A/C: | Kinglong
roof mounted dependent A/C (Bitzer compressor 22000KCal) with ventilation and
air filtrating function |
| Seats: | Deluxe
BK01 seats(high back rest; adjustable; horizontal moving) |
| Driver
seat (high backrest; shock absorption; adjustable) |
| Door: | Front
pneumatic out-swing door (double sealed) |
| Window: | Sticked
sealed side window (both rear side windows are semi-sliding) |
| Two
emergency exit roof windows |
| Others: | Front
windshield with defroster; Luggage compartment > 3.3/3.6m3; Front sun visor;
Washable inner decoration with read lamp;Digital clock with thermometer and hygrometer;
Remote control passenger door lock; |
| | |
| |
KLQ6856/Q |
KLQ6896Q |
| Standard
seat number: | 31+1 | 35+1 |
| Overall
dimensions(mm) : | 8490
x 2420 x 3345 | 8820
x 2420 x 3345 |
| Max.
speed(km/h): | 110 | 115 |
| Kerb
mass(kg): | 7700 | 8150 |
| Fuel
tank(L): | 220 | 220 |
