CHASSIS |
6101G (C) |
6116G |
| Engine | YC6J210-20,YC6G230-20,6C230-2,EQB210-20,ISBE220
31(EURO III) .9-230G,EQD210N-20(CNG) | YC6G240-20,YC6G270-20,6HE1,ISBE220
31(EUROIII) ,ISCe 260 30(EUROIII),DAF 183E |
| Clutch: | diaphragm
spring clutch/hydraulic clutch | diaphragm
spring clutch |
|
Transmission | QiJiang
QJ805/Hachi 5speed manual gearbox/VOITH Auto transmission | QiJiang
QJ805 /1205 5speed manual gearbox |
| Suspension | Leaf
spring suspension with front/rear stabilizer bar | Leaf
spring suspension with front/rear stabilizer bar |
| Axle | front
and rear axle | EQ153
/dongfeng 13T * front and rear axle |
| Steering | Power
steering gearbox | Power
steering gearbox |
|
Braking | Front
/rear drum braker;dual circuit air braking system ;Parking brake acting on rear
axle | Front
/rear drum braker;dual circuit air braking system ;Parking brake acting on rear
axle |
|
Tyre: | 9.0-20
bias tyre/9.0R20 radial tyre | 11R22.5
tubeless tyre |
|
Others | Auto
slack adjustor; WABCO ABS*; retarder*;/integrate retarder,lubricating centre* | Auto
slack adjustor;retarder; WABCO ABS*; lubricating centre* |
| BODY |
| A/C | Higer
roof mounted dependent A/C(BOCK compressork,25.6Kw) with ventilation, air filtrating
funtion* | Higer
roof mounted dependent A/C(BOCK compressor,27.8Kw) with ventilation, air filtrating
funtion* |
|
Heater | Front
windowscreen defroster,independent/dependent heater* | Front
windowscreen defroster,independent/dependent heater* |
| Seats | Engineering
plastic passenger seat (ABS seats),Driver seat (high backrest, shock absorption
and adjustable) |
|
Door | Rear
double/Front single pneumatic inward-swing door,two step entry | Front/Rear
double pneumatic inward-swing door,two step entry |
| Windows | below
sealed up slided aluminous frame window( driver window and rear side window is
sliding style) | below
sealed uper slided aluminous frame window( driver window and rear side window
is sliding style) |
|
Lighting | Inner
strip ceiling light; step lamps; high position brake lamp* | Inner
strip ceiling light; step lamps; high position brake lamp* |
| Others | RHD*
protected fence,spray plastic handrail, radio and player digital clock*;guidepost*;spot
displayer and messenger*;coin collecting machine*;driver fan,back up monitor*,VCD* |
| SPECIFICATION |
| Standard
seat number | 31+1 | 37+1 |
| Overall
dimensions(mm) | 10250X2480X2900(3100) | 11460X2480X2900(3100) |
| Rated
passenger | 75 | 95 |
| Max.
Speed(Km/h) | 85 |
| Kerb
Mass/GVW(kg) | 9400/15000/ | 9900/17500 |
| Fuel/
CNG tank (L) | 200//8¡Á80L | 200 |
| Entry
height(F/R)(mm) | 350/375 | 350/380 |
